| Details of whole set equipment and steel structure of blast furnace for sale |
| equipment name |
type |
| Water supply and drainage system |
|
| electric butterfly valve |
HD944P-2.5DN1200 |
| Electrical instrument automation system |
|
| Pulverized coal explosion-proof bag type dust collector |
PBPPCS128-2*6 |
| bleeder valve |
FS746H-2DN400 |
| Micropowered dust collector |
HMC-II |
| 2# Dedusting cover for furnace outlet |
2 # furnace |
| Accurate measurement and intelligent early warning system of temperature difference heat load of blast furnace cooling water |
V1.0 |
| Double preheating heat exchanger for blast furnace flue gas, air and gas |
SYR580HRQ |
| 2# heat exchanger pipeline |
2 # furnace |
| Intelligent controlled combustion instrument system for hot blast furnace no. 2 |
ZNSLU -16 |
| 2# blast furnace dedusting field |
|
| blast furnace proper |
|
| power cable |
|
| electric instrument |
|
| combustion fan |
SN9-19-11NO9D |
| pipeline |
|
| Blast furnace subtrough system |
|
| crown block |
|
| electric hoist |
|
| hydraulic pressure station |
|
| 530m3 blast furnace gas automatic ash removal pulse bag filter |
|
| Top feeder support |
|
| power transformer |
S9-1600 |
| nitrogen container |
10m3 |
| Compressed air pack |
0.23m3 |
| steam pockets |
0.5m3 |
| direct current cabinet |
GZDW-100/220 |
| ZMAY |
ZMAN-40KDN150 |
| Pneumatic piston quick - cut valve |
ZSPQ-40KDN150 |
| cooling wall |
|
| Humidify and unload the aircraft |
HSW-30 |
| Star discharge device |
YGD300*300 |
| electric butterfly valve |
HD944P-1.5DN800 |
| DLVD |
HF9T43X-1.5DN800 |
| DLVD |
HF9744X-2.5DN1200 |
| DLVD |
HF9744X-2.5DN1800 |
| electric butterfly valve |
HD944P-2.5DN1800 |
| Top pumping device Rd2801 |
1.6Mpa，0.55kwRd2801 |
| CBZ |
CBZ |
| belt conveyor |
SJ2-1 |
| belt conveyor |
SK2-1 |
| belt conveyor |
K2-2 |
| belt conveyor |
K2-1 |
| Blast furnace measuring device |
|
| Coke vibrating screen and gate |
LHBXBSFJ135*300-I |
| Sintering feeder, vibrating screen and gate |
LHBXBSFJ125*280-ILHBRZG90*90F-II |
| Pellet shaker and gate |
LHBXBSFJ125*280-I |
| Coke ding vibrating screen and gate |
LHBXBSFJ105*260-II |
| Mixed ore feeder and gate |
LHBRZG80*185-II |
| High voltage switchgear and accessories for main control building |
|
| Instrument automation transmission equipment |
|
| dust-collecting fan |
LCMG-3500*2 |
| Gas automatic ash removal pulse bag filter |
|
| low voltage switchgear cabinet |
|
| low voltage switch box |
|
| GDTA |
DN1800，L=800△L=150 |
| GDTA |
DN1200，L=800，△L=160 |
| GDTA |
DN800，L=800，△L=150 |
| hot blast heater |
|
| tuyere small sleeve |
115*360斜3度 |
| tuyere small sleeve |
620*350 |
| Blast furnace trench dust removal system |
XLCM5500m² long bag low pressure pulse bag filter |
| Blast furnace gas pressure regulating valve set and matching silencer |
1800TYFZ-2.5CRF-CMX-1S |
| Automatic dedusting system of 530m3 blast furnace gas, pulse bagging and dedusting |
|
| Tank hydraulic station |
|
| Hydraulic station in front of the furnace |
|
| Hydraulic clay gun |
KD100(two sides ) |
| The hanging and tensioning device of the peripheral pipe of the 530 blast furnace |
|
| Ionizing radiation material level meter and probe |
LWJ-87 |
| Double beam bridge crane |
QD16T-28m |
| A complete set of blast furnace air supply device |
|
| MULTIDOS |
ZD-JGC30-650 |
| bend pulley |
B=1000400# |
| transmission drum |
B=1000842# |
| Even pressure release valve |
QP742DN300 |
| pressure equalizing valve |
QP742DN200 |
| Secondary pressure equalizing valve |
DN200 |
| bleeder valve |
FS743Y-2.5CDN550 |
| gas release valve |
FS746PH-2DN200 |
| Brake valve and electric winch |
19Y48Y-2.5DN2150 |
| Charging device for 530 vertical blast furnace |
|
| Hydraulic opening machine |
KD-IIA(GXTA型) |
| Bell-less top of Blast furnace |
|
| J5 belt conveyor |
|
| Q2 belt conveyor |
|
| S3 belt conveyor |
|
| 2# blast furnace body, surrounding tube above 6 with furnace shell |
|
| exhaust system |
|
| No. 2 blast furnace trench dust removal |
|
| No. 2 blast furnace top equalizing gas recovery device |
|
| blast blower |
AV45-12 |
| Blast furnace accessor-blower system compensator batch |
SDF6-1000-2000 |
| Blast furnace accessories - blower system - pressure regulating valve set, valves |
non-standard |
| Blast furnace accessory - blower system - self - cleaning air filter |
non-standard |
| Blast furnace accessory - blower system - motor |
AV45 |
| Blast furnace accessory - blower system |
steel structure |
| 2# Dedusting cover for furnace outlet |
iron mill |
| 2# heat exchanger pipeline |
iron mill |
| pipeline |
iron mill |
| 2#、3# blast furnace dust connection pipeline |
iron mill |
| steel platform |
iron mill |
| Pipe brackets and platforms |
iron mill |
