The HZD-B-6d explosion-proof vibration transmitter transmits the acceleration sensor or vibration velocity
The sensor and the precision measurement circuit are integrated together, achieving the traditional "sensor + monitoring"
The function of the vibration measurement system in the "measuring instrument" mode is suitable for building an economical and high-precision type
The degree vibration measurement system, this transmitter can be directly connected to DCS, PLC or other systems
It is an ideal choice for vibration measurement of factory equipment such as fans and pumps.
The HZD-B-6d explosion-proof vibration transmitter is in accordance with GB/T
3836.1-2021.
"Explosive Environment"
Part 1: Equipment
General Requirements, GB/T
3836.2-2021 "Explosive Atmospheres - Part 2: Protected by Flameproof Enclosures' d
The equipment is made of flameproof explosion-proof structure with the transmitter, which has been authorized by the state for quality
The supervision and inspection department has inspected and found it qualified. Its explosion-proof mark is Ex db IIC T6 Gb.
This transmitter is applied in the presence of combustible materials of Class ⅡA, ⅡB and IIC, and groups T1 to T6
Explosive hazard areas of Zone 1 and Zone 2 formed by the mixture of flammable gases, vapors and air
